| STAGEPAS 1K mkII | ||
|---|---|---|
| STAGEPAS 1K mkII | ||
|---|---|---|
| Outline | ||
| Type | Powered subwoofer with a line array speaker | |
| Mixing capability | Mixing channels | 5 (Mono x3 + Stereo x1) |
| Input channel functions | Hi-Z: CH2/3, 1-knob EQ: CH1-3/ST | |
| Output channel functions | MODE (SPEECH/MUSIC/CLUB) | |
| I/O | Inputs | Mono x3 (mic/line) + Stereo x1 (line) / Mono x2 (line), Link in x1 |
| Outputs | Link out x1, Monitior out x1 | |
| Bluetooth | Bluetooth Ver.5.0, A2DP (SBC, AAC) | |
| Control and others | Reverb foot switch, STAGEPAS Controller (iOS/Android app) | |
| On-board processors | DSP | SPX digital reverb (4 program, parameter control) |
| General specifications | ||
| Speaker type | Powered subwoofer: Bass-reflex type, Line array speaker: Enclosed | |
| Frequency range (-10dB) | 37 Hz - 20 kHz | |
| Coverage area | H170ﾟ x V30ﾟ | |
| Crossover | 240 Hz | |
| Maximum output level (1m; on axis) | 125 dB SPL | |
| Components | LF | Powered subwoofer: 12” (30 cm) Cone |
| HF | Line array speaker: 1.5” (3.8 cm) Cone x 10 | |
| Amplifier class | Class-D | |
| Power rating | Dynamic | 1100 W |
| Power consumption | 25 W (Idle), 91 W (1/8 power) | |
| Power requirements | Depending on area of purchase: 100 V 50 Hz/60 Hz, 110-120 V 60 Hz, 220 V-240 V 50 Hz/60 Hz | |
| Handle | Top of powered subwoofer x1 | |
| Dimensions (W x H x D) | System: 334 x 2,000 x 418 mm (maximum), Line array speaker: 67 x 582 x 86 mm, Powered subwoofer: 334 x 550 x 418 mm, Spacer: 67 x 555 x 86 mm (each) | |
| Weight | System: 23.0 kg (maximum), Line array speaker: 1.8 kg, Powered subwoofer: 20.0 kg, Spacer: 0.6 kg (each) | |
