| Turntable | |
|---|---|
| Type | 3-speed, fully manual operation |
| Motor | DC servo motor |
| Drive Method | Direct drive |
| Speeds | 33-1/3 RPM, 45 RPM, 78 RPM |
| Turntable Platter | Die-cast aluminum |
| Starting Torque | >1.0 kgf.cm |
| Braking System | Electronic brake |
| Wow and Flutter | <0.2% (WTD) @ 3 kHz (JIS) |
| Signal-to-Noise Ratio | >50 dB |
| Output Level | Pre-amp “PHONO”: 4 mV nominal at 1 kHz, 5 cm/sec Pre-amp “LINE”: 240 mV nominal at 1 kHz, 5 cm/sec |
| Phono Pre-Amp Gain | 36 dB nominal, RIAA equalized |
| USB Function | A/D, D/A – 16-bit/44.1 kHz or 48 kHz USB selectable; Computer interface – USB 2.0 Compliant Windows 7 or above, or MAC OS X or above |
| Power Supply Requirements | 100 to 240 V, 50/60 Hz, 1.5A Max |
| Power Consumption | 2.75 W |
| Dimensions | 452.0 mm (17.80") W x 352.0 mm (13.86") D x 141.6 mm (5.57") H |
| Weight | 8 kg (17.6 lbs.), without dust cover |
| Accessories Included | AT-VM95E phono cartridge; AT-HS6 headshell; 1.9 m (6.2') USB cable; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; felt mat; dust cover; 45 RPM adapter; plug-type stylus target light |
| Tonearm Type | Balanced S-shaped tonearm with detachable headshell |
| Effective Arm Length | 230.5 mm |
| Overhang | 16 mm |
| Tracking Error Angle | Less than 3 degrees |
| Applicable Cartridge Weight | 3.5-8.5 g |
| Anti-skating Range | 0-4 g |
| Replacement Stylus | AT-VMN95E |
| Communication System | Bluetooth Version 5.0 |
| Maximum Communication Range | Line of sight - approx. 10 m (33') |
| Compatible Bluetooth Profile | A2DP |
| Support Codec | Qualcomm® aptX™ Adaptive audio, Qualcomm® aptX™ audio, SBC |
